Show Your Vintage MTB Drop Bar Conversions

Classic & Vintage This forum is to discuss the many aspects of classic and vintage bicycles, including musclebikes, lightweights, middleweights, hi-wheelers, bone-shakers, safety bikes and much more.

Show Your Vintage MTB Drop Bar Conversions

Old 06-12-19, 06:49 AM
  #6451
Cl904
Senior Member

Join Date: Aug 2018
Posts: 305
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 101 Post(s)
Likes: 0
Liked 19 Times in 15 Posts


Now with Shimano 600ex levers and suntour barcons.
Cl904 is offline
Likes For Cl904:
Old 06-12-19, 09:59 AM
  #6452
due ruote
Senior Member

due ruote's Avatar

Join Date: Dec 2006
Posts: 6,688
Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 489 Post(s)
Likes: 0
Liked 12 Times in 11 Posts
Originally Posted by belacqua View Post
Question for you all--I want to try my '94 stumpjumper as a drop bar, but I can't get the bars high enough while keeping the reach manageable.

what do you think about putting a new aftermarket fork in (1'' threadless, 260mm steerer) and using spacers to get the stem mounted high on the steerer?

also, any recommendations on a fork that would work?
Is the stock fork threadless, or are you using an adapter?
due ruote is offline
Old 06-12-19, 10:01 AM
  #6453
belacqua
Senior Member

Join Date: Sep 2008
Location: Kansas City
Posts: 363
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Liked 4 Times in 3 Posts
stock is 1" threadless!

also, the Dimension forks I'm looking at have 26 cm steerer, which seems like it would give me about 5cm of additional rise over what I've got now. Maybe something with even longer steerer might be available?

Last edited by belacqua; 06-12-19 at 10:04 AM.
belacqua is offline
Old 06-12-19, 10:06 AM
  #6454
bark_eater
Senior Member

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 446

Bikes: Road ready: 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 161 Post(s)
Liked 1 Time in 1 Post
Originally Posted by belacqua View Post
stock is 1" threadless!

also, the Dimension forks I'm looking at have 26 cm steerer, which seems like it would give me about 5cm of additional rise over what I've got now. Maybe something with even longer steerer might be available?
Could you have the original fork steerer threaded and use a quill stem?
bark_eater is offline
Old 06-12-19, 10:28 AM
  #6455
belacqua
Senior Member

Join Date: Sep 2008
Location: Kansas City
Posts: 363
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Liked 4 Times in 3 Posts
I hadn't thought of this--thanks for the idea. My initial thought is I wouldn't want to try installing a new headset in my garage if I could avoid it, and the new threadless forks run about $80, so it would be hard to beat the economy and simplicity of swapping.
belacqua is offline
Old 06-12-19, 10:32 AM
  #6456
belacqua
Senior Member

Join Date: Sep 2008
Location: Kansas City
Posts: 363
Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 75 Post(s)
Liked 4 Times in 3 Posts
but here's the other question I'm grappling with today--what do I really stand to gain by putting drops on this rig--favorite mtb in my small collection--when I already have bar ends.

Not a rhetorical question. I am hoping to use the thing for 5+ hour gravel rides.
belacqua is offline
Old 06-12-19, 11:43 AM
  #6457
bark_eater
Senior Member

Join Date: Sep 2017
Location: Eastern Shore, MD
Posts: 446

Bikes: Road ready: 1989 Centurion Sport DLX, "I Blame GP" Bridgestone CB-1. Projects: Yea, I got a problem....

Mentioned: 6 Post(s)
Tagged: 0 Thread(s)
Quoted: 161 Post(s)
Liked 1 Time in 1 Post
Originally Posted by belacqua View Post
I hadn't thought of this--thanks for the idea. My initial thought is I wouldn't want to try installing a new headset in my garage if I could avoid it, and the new threadless forks run about $80, so it would be hard to beat the economy and simplicity of swapping.
You would have to confirm that the Inner diameter of the steerer is correct but I dont think you would need a new head set. If you have the longer steerer is threaded you could use a spacer under a 1" nut and lock ring.
bark_eater is offline
Old 06-12-19, 01:27 PM
  #6458
Squeeze
High Plains Luddite

Join Date: Jul 2013
Location: Colorado
Posts: 577

Bikes: '90s MTBs, '96 Allez

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 144 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
Originally Posted by belacqua View Post
stock is 1" threadless!


Thank you for sharing this information. I bet I'm not the only one who learned from this.

I've heard of 1" threadless but haven't seen it before. Recently I was looking at a '95 Trek 990 in my size on craigslist. Like yours, it had its original matching rigid fork (always highly desirable to me) and a stem that looked a lot like the one on your Stumpjumper. I figured someone had used a threaded-to-threadless converter and liked the "slammed" stem look. I would have wanted to put drop bars on it and would have had no idea what I was getting into. Fortunately for me, the seller was asking WAY too much for the bike, but it was fun to think about for a while.

Last edited by Squeeze; 06-12-19 at 01:31 PM.
Squeeze is offline
Old 06-12-19, 01:32 PM
  #6459
ksryder
Senior Member

Join Date: May 2014
Posts: 1,813

Bikes: yes

Mentioned: 13 Post(s)
Tagged: 0 Thread(s)
Quoted: 724 Post(s)
Liked 61 Times in 34 Posts
MTBs started using threadless and/or 1-1/8" head tubes way way way before they moved to road bikes. In the 90s it seems like it was the wild west as far as what spec you would find on any particular bike. On the same model years you might find a quill stem with an oddball diameter on one bike, but on a different make you'll find 1" threadless. It was wild.
ksryder is online now
Old 06-12-19, 01:42 PM
  #6460
due ruote
Senior Member

due ruote's Avatar

Join Date: Dec 2006
Posts: 6,688
Mentioned: 17 Post(s)
Tagged: 0 Thread(s)
Quoted: 489 Post(s)
Likes: 0
Liked 12 Times in 11 Posts
Originally Posted by belacqua View Post
but here's the other question I'm grappling with today--what do I really stand to gain by putting drops on this rig--favorite mtb in my small collection--when I already have bar ends.

Not a rhetorical question. I am hoping to use the thing for 5+ hour gravel rides.
https://www.rivbike.com/products/nit...ess-stem-16252

What are thoughts on using one of those with a shim?
due ruote is offline
Old 06-12-19, 07:59 PM
  #6461
t_e_r_r_y
Senior Member

t_e_r_r_y's Avatar

Join Date: Apr 2019
Location: oregon coast
Posts: 140
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 34 Post(s)
Liked 17 Times in 11 Posts
Originally Posted by belacqua View Post
but here's the other question I'm grappling with today--what do I really stand to gain by putting drops on this rig--favorite mtb in my small collection--when I already have bar ends.

Not a rhetorical question. I am hoping to use the thing for 5+ hour gravel rides.
drops will give you a bunch more hand positions, which is great for those longer rides. personally i run drops higher than i would flats on these bikes, like so that the drops are about where my hands would be height-wise on flats. this gives me a more comfortable up-right position when riding on the tops of the drops, or in the hoods, and i'm still comfortable when going into the drops
t_e_r_r_y is offline
Old 06-17-19, 08:18 PM
  #6462
shipwreck
Senior Member

shipwreck's Avatar

Join Date: Mar 2009
Posts: 1,477
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 139 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
follow up on post 6414, some shots of a drop conversion in action. A freind wanted to do the new adventure cycling Arkansas high country loop. https://bikepacking.com/routes/arkan...orthwest-loop/
Since I don't own a real gravel bike, and did not want to ride 240 miles on a flat bar, took the Gary Fischer Marlin. Used my regular panniers. We did it in three days. I lived. The last day riding home was fifty miles of rain, which felt really good on the 150+ mosquito bites. Really, we counted when the swelling went down enough to see them. The other guys got about ten or so each.
  1. DISTANCE

    242 Mi.

    (389 KM)
  2. DAYS

    3-4
  3. % UNPAVED

    51%
  4. % SINGLETRACK

    0%
  5. DIFFICULTY (1-10)

    4
  6. % RIDEABLE (TIME)

    100%
  7. TOTAL ASCENT

    18,920'

    (5,767 M)
  8. HIGH POINT

    2,511'




shipwreck is offline
Old 06-20-19, 04:50 PM
  #6463
NocoRider
Member

Join Date: Dec 2013
Location: Northern Colorado
Posts: 30

Bikes: 3 Frankenbikes (Stumpjumper, Karakoram, Trek 930), Fuso, Tarmac Pro, '72 Fuji Finest, Soma Saga, El Diente, Cannondale tandem, 2 mountain bikes, more...

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
FYI...

How to get a Road Front Derailleur to work on a Mountain Bike frame...

The 73 mm wide MTB bottom bracket shell prevents use of some road front derailleurs as they are designed a 68 mm road BB bracket shell. This problem is most common for folks trying to use brifters (STI, Ergo Shifters, Double Tap) which work best when used as a complete system including the front derailleur.

The fix I used for this issue was to use larger clamp for the FD and fashion a shim using pieces of old inner tubes to make a shim which would push the derailleur about 3mm farther to the right. It just took a bit of patience and some contact cement...

-OR- for those who want an engineered solution

Check out this Jtek Eccentric Shim:

Jtek Eccentric Shim for Front Derailleur

Disclaimer: I have no association with Jtek but I do think this product is useful for making drop bar mountain bikes.
NocoRider is offline
Old 07-03-19, 08:13 AM
  #6464
RyanAK
Member

Join Date: Apr 2019
Posts: 34
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 12 Times in 9 Posts
Geez, this thread is fantastic! Love the creativity and practicality in these builds. Good on yas!

I’m in the beginnings of putting together my ‘97 MUSA Trek 820 from my college days as a drop bar all-rounder. My 4yo son wanted to paint it so I stripped everything off, stripped the frame, and Spencer and I gave it a pretty good rattle-can paint job. Slowly going back together, and it’s been really special to do this with Spence. Hope when it’s done it rides half as good as some of your builds look!


RyanAK is offline
Likes For RyanAK:
Old 07-03-19, 05:59 PM
  #6465
rustystrings61
Senior Member

Join Date: May 2013
Location: Greenwood SC USA
Posts: 753

Bikes: 2002 Mercian Vincitore, 1982 Mercian Colorado, 1971 Gitane Tour de France, 1991 Diamond Back Venture

Mentioned: 28 Post(s)
Tagged: 0 Thread(s)
Quoted: 260 Post(s)
Liked 28 Times in 18 Posts
Older 24-in wheel Trek 800 built up with MicroNEW 3x7 brifters for my 12 year old son.


rustystrings61 is offline
Likes For rustystrings61:
Old 07-03-19, 07:30 PM
  #6466
RyanAK
Member

Join Date: Apr 2019
Posts: 34
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 12 Times in 9 Posts
Very cool, Rusty! Little man will have a blast!

Working on sorting out the cockpit on the 820. These are Soma Portolas, and they’re a new shape for me. Fiddling with lever position... and the little doodads where the cable housing meets the levers seems an odd size. Housing is loose in the nipple but a housing end seems too big to fit right. Thinking about cable routing too. Both shifter cables run the bottom tube. Rear brake on the top tube. Advice on setting things up appreciated!

Still deciding on what to run for a rack / basket / bag up front. I have Carradice Barley and Pendle saddlebags that I considered hanging from the bars, but with the non-aero levers and the really tall stem, not sure this will work. Leaning towards a rack with either a basket and bag or a rando bag. Thoughts? Anyone have a canti-mount front rack they’re not using?

Bikes are fun, eh?

RyanAK is offline
Likes For RyanAK:
Old 07-03-19, 07:44 PM
  #6467
t_e_r_r_y
Senior Member

t_e_r_r_y's Avatar

Join Date: Apr 2019
Location: oregon coast
Posts: 140
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 34 Post(s)
Liked 17 Times in 11 Posts
Originally Posted by RyanAK View Post
Working on sorting out the cockpit on the 820. These are Soma Portolas, and they’re a new shape for me. Fiddling with lever position... and the little doodads where the cable housing meets the levers seems an odd size. Housing is loose in the nipple but a housing end seems too big to fit right. Thinking about cable routing too. Both shifter cables run the bottom tube. Rear brake on the top tube. Advice on setting things up appreciated!

Still deciding on what to run for a rack / basket / bag up front. I have Carradice Barley and Pendle saddlebags that I considered hanging from the bars, but with the non-aero levers and the really tall stem, not sure this will work. Leaning towards a rack with either a basket and bag or a rando bag. Thoughts? Anyone have a canti-mount front rack they’re not using?

Bikes are fun, eh?
awesome bike! it reminds me a lot of the direction i'm going with my univega. very similar. what kind of gearing are you going to run? are you using bar end shifters? if so, you could have the housing exit the bar tape a few wraps in and just loop down to your downtube, that's how i set up my specialized and it works great. seems like a typical solution.

not sure what to tell you on the rack/bag situation, i'll be running a rack on mine for sure. i kind of have my eyes on the blackburn bootlegger rack at the moment, i like a wide rack.

bikes are super fun
t_e_r_r_y is offline
Old 07-03-19, 07:57 PM
  #6468
RyanAK
Member

Join Date: Apr 2019
Posts: 34
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked 12 Times in 9 Posts
Going to stay with the original Shimano Altus 3x7 for now. Well... Altus except for the Alivio RD. Everything is in good shape now that it’s all been removed and cleaned/maintenance done. Shimano 8sp bar-ends. I originally thought to have the housing exit the bar tape from the drops after a few wraps, but wonder about clearing whatever rack/basket/bag I run. A basket or big-ish bag may get in the way of the big loops running forward and turning back to the downtube. But maybe not...

hmmm....

RyanAK is offline
Likes For RyanAK:
Old 07-04-19, 12:44 AM
  #6469
Sp1990
Senior Member

Join Date: Jun 2019
Posts: 56
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Likes: 0
Liked 7 Times in 6 Posts
Has anyone on here done the opposite of this, a roadbike to a mtb?
Sp1990 is offline
Old 07-04-19, 03:08 AM
  #6470
Pompiere
Senior Member

Join Date: Nov 2005
Location: NW Ohio
Posts: 2,460

Bikes: 1984 Miyata 310, 1986 Schwinn Sierra, 2011 Jamis Quest, 1980 Peugeot TH8 Tandem, 1992 Performance Parabola, 1987 Ross Mt. Hood, 1988 Schwinn LeTour, 1988 Trek 400T

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 216 Post(s)
Liked 7 Times in 6 Posts
Originally Posted by Sp1990 View Post
Has anyone on here done the opposite of this, a roadbike to a mtb?
I think that is what's going on with the gravel bike conversions. Everyone is asking "how big a tire will fit in my old road bike frame".
Pompiere is offline
Old 07-04-19, 01:38 PM
  #6471
wrk101
Thrifty Bill
Thread Starter

wrk101's Avatar

Join Date: Jan 2008
Location: Mountains of Western NC
Posts: 22,014

Bikes: 86 Katakura Silk, 87 Prologue X2, 88 Cimarron LE, 1975 Sekai 4000 Professional, 73 Paramount, plus more

Mentioned: 67 Post(s)
Tagged: 0 Thread(s)
Quoted: 648 Post(s)
Likes: 0
Liked 38 Times in 33 Posts
+10 Tire width will get you. 1980s rigid frame MTBs are plentiful, at reasonable to low pricing. And they tend to have more reasonable top tube length. Later MTBs got really long top tubes, making them more of a challenge to convert to drops and get them to fit.

To get cantilever brakes on a road bike, you are talking touring bike, and touring bikes tend to be at the higher end price wise. I've got Fat Franks on one of my conversions, those tires are 2.35 inches wide which is approximately 60mm wide. I haven't seen a road bike that can handle anything close to that.

I have used my Prologue racing bike with 25mm tires on packed gravel trails. Just have to keep your awareness up. Obviously not ideal or anything I would recommend. Had I lost control and wiped out, I would be kicking myself for sure.
wrk101 is offline
Old 07-04-19, 04:03 PM
  #6472
misctrader
Senior Member

Join Date: Jun 2016
Posts: 54
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 20 Post(s)
Likes: 0
Liked 2 Times in 1 Post
Schwinn Cimarron

misctrader is offline
Likes For misctrader:
Old 07-04-19, 04:12 PM
  #6473
Lemond1985
Sophomore Member

Lemond1985's Avatar

Join Date: Jan 2019
Posts: 1,434
Mentioned: 10 Post(s)
Tagged: 0 Thread(s)
Quoted: 789 Post(s)
Liked 149 Times in 108 Posts
Originally Posted by wrk101 View Post
I have used my Prologue racing bike with 25mm tires on packed gravel trails. Just have to keep your awareness up. Obviously not ideal or anything I would recommend. Had I lost control and wiped out, I would be kicking myself for sure.
No kidding. So off-road funnybiking is a thing these days, is it?

Lemond1985 is offline
Old 07-05-19, 07:12 PM
  #6474
Sp1990
Senior Member

Join Date: Jun 2019
Posts: 56
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Likes: 0
Liked 7 Times in 6 Posts
Originally Posted by Pompiere View Post
I think that is what's going on with the gravel bike conversions. Everyone is asking "how big a tire will fit in my old road bike frame".
Old roadbikes are always being given to me or on the curb but I dont have a need for another roadbike. Now a gravel grinder or old mtb i definitely have a need for.
Sp1990 is offline
Old 07-05-19, 09:10 PM
  #6475
Cycle Tourist
Senior Member

Join Date: Jan 2017
Posts: 223
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 60 Post(s)
Likes: 0
Liked 8 Times in 8 Posts
Originally Posted by leftthread View Post
Do you think a drop bar conversion would also work well with a flat-bar hybrid frame, 700c/35 wheels?
Oh yes definitely. I thought I'd built a tough touring bike with a hybrid conversation, (fenders and all), until I saw these awesome bikes!
Cycle Tourist is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

Copyright © 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
