The Thirst For Knowledge,Bar End Shifters

I have only been wrenching on old steel for a short time and have a lot to learn.
I like the bar end shifters on my Surly LHT and would like to put some on one or two of my vintage steel bikes.
I see a lot of love for old Suntour barcons and i see that new bar end shifters are available from different makers.
Any recommendations on good shifters? What tidbits of knowledge do you have for a newbie on this subject? THanks in advance.
garryg is offline
Old 09-03-19, 10:47 PM
  #2
Jeff Wills
Insane Bicycle Mechanic

Jeff Wills's Avatar

Join Date: Mar 2008
Location: other Vancouver
Posts: 9,056
Mentioned: 28 Post(s)
Tagged: 0 Thread(s)
Quoted: 467 Post(s)
Liked 51 Times in 37 Posts
The "vintage" SunTour units are very common and the class of the field for many reasons. Because they were so common and durable they're easy to find and affordable.

I've used Shimano indexing barcons on several bikes since they became available in the late '80's. They are also bombproof, but you need to match them to the number of cogs on the rear wheel. You need to remember to tighten the center screw very tightly to prevent the indexing unit from self-destructing.

Common to all bar-end shifters: the screw that clamps the shifter inside the bar operates backwards: righty-loosey, lefty-tighty. It's still a right-hand thread, you're just tightening it from the opposite end.

Shimano bar-con PDF:
https://si.shimano.com/pdfs/ev/EV-SL-BS77-1664.pdf

__________________
Jeff Wills

Comcast nuked my web page. It will return soon..
Jeff Wills is offline
Old 09-04-19, 12:04 AM
  #3
merziac
Senior Member

merziac's Avatar

Join Date: Oct 2015
Location: PDX
Posts: 4,432

Bikes: Merz x 5 + Specialized Merz Allez x 2, Strawberry/Newlands/DiNucci x2, Gordon, Fuso/Moulton, Bornstein, Paisley, Paramounts, 3rensho, Moto TC, Raleigh Pro's, Marinoni, 1960 Cinelli SC, 1980 Bianchi SC and more

Mentioned: 110 Post(s)
Tagged: 0 Thread(s)
Quoted: 1238 Post(s)
Liked 143 Times in 117 Posts
Originally Posted by garryg View Post
I have only been wrenching on old steel for a short time and have a lot to learn.
I like the bar end shifters on my Surly LHT and would like to put some on one or two of my vintage steel bikes.
I see a lot of love for old Suntour barcons and i see that new bar end shifters are available from different makers.
Any recommendations on good shifters? What tidbits of knowledge do you have for a newbie on this subject? THanks in advance.
Get a set of Suntour's first, figure them out, not hard, work them into your routine, run with it. They have their quirks, nothing epic and you have to get the hang of cabling and wrapping to your taste, the downtube cable stop needs to be tight, just like shifters so they don't scrape the paint off.

What are the ones on the LHT? I assume they were on it when you got it so you will have a good comparison to others and also a good basic understanding already which is good.

Make it so.
merziac is online now
Old 09-04-19, 07:41 AM
  #4
BFisher
Senior Member

BFisher's Avatar

Join Date: Aug 2013
Location: NEPA
Posts: 482

Bikes: '61 Schwinn Klunker, '68 Hercules Klapprad, '71 Peugeot UO8, '78 Motobecane Grand Jubile, '79 Motobecane Grand Sprint, '87 Ironman Expert, '89 Puch Mistral Leader, '92 Trek 930

Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 109 Post(s)
Liked 98 Times in 72 Posts
The old Suntour bar-end shifters really are great parts. Sometimes the axle lock nut (part #16 above) is missing as they can back out and fall off. Functionally, they are excellent.

I'd also point out the older Shimano "fingertip control" bar-end shifters. They are, in my opinion, also excellent. They have a return spring inside and have a pretty nice feel to them. They are also friction only. I wouldn't hesitate to use them.
BFisher is offline
Old 09-04-19, 10:01 AM
  #5
CliffordK
Senior Member

CliffordK's Avatar

Join Date: Nov 2014
Location: Eugene, Oregon, USA
Posts: 22,930
Mentioned: 178 Post(s)
Tagged: 0 Thread(s)
Quoted: 9148 Post(s)
Liked 188 Times in 151 Posts
The early Campagnolo bar end shifters were friction only. I haven't tried them. Lots of better options available.

Shimano (Dura Ace?), contemporary with the vintage Suntour bar end shifters were springy. They do have a slightly greater travel range than the Suntour, but are too springy at the released cable, and not springy enough at the maximum cable pull. Nonetheless, a solid shifter for the typical 6/7 spd range.
CliffordK is offline
Old 09-04-19, 10:10 AM
  #6
tyler_fred
Senior Member

tyler_fred's Avatar

Join Date: Nov 2010
Location: Magnolia State, 100į with 110% humidity
Posts: 948

Bikes: American, Italian, and Japanese.. in no particular order.

Mentioned: 16 Post(s)
Tagged: 0 Thread(s)
Quoted: 213 Post(s)
Likes: 0
Liked 17 Times in 14 Posts
Another option is to take Shimano or Rivbike pods and add your down tube shifters..
Attached Images
File Type: jpg
tyler_fred is offline
Old 09-04-19, 10:41 AM
  #7
Slightspeed
Senior Member

Slightspeed's Avatar

Join Date: Apr 2017
Location: Los Angeles, CA
Posts: 1,732

Bikes: 1961 Legnano Gran Premio, 1964 Legnano Roma Olympiade, 1973 Raleigh Super Course, 1978 Raleigh Super Course, 1978 Peugeot PR10, 2002 Specialized Allez, 2007 Specialized Roubaix, 2013 Culprit Croz Blade

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 542 Post(s)
Likes: 0
Liked 182 Times in 121 Posts
Being a downtube shifter hater, I love my bar cons, with preference to Suntour with the ratchet clicks. I find them more precise and just easier to use in friction mode than my Campy ones, that I have been riding since 1964. Over 50 + years of riding I've managed to avoid DT shifters, but I now have two in my collection, Simplex on a '78 Peugeot PR10, and old Campy DTs on a '61 Legnano that I just couldn't resist. I actually had a set of Suntour bar cons for the PR10, but before I could get them switched, a needy Raleigh Super Course showed up that got them. The cable routing makes for lively discussion, but as for me, rather than having them hanging out in the breeze, I like mine tucked up under the bar tape, exiting near the stem. I find that they shift great, and don't snag on everything that passes near them, and just look more tidy.

Suntours on a recent build '78 Raleigh. With aero brake levers and shifter cables, it gets crowded under the bar tape, but it works for me, and I like the clean look.


Campy bar ends on my '64 Legnano, 55 years of trouble free operation, just don't feel as nice as the Suntours.
Slightspeed is offline
Likes For Slightspeed:
Old 09-04-19, 10:47 AM
  #8
Cycle Tourist
Senior Member

Join Date: Jan 2017
Posts: 300
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 96 Post(s)
Likes: 0
Liked 19 Times in 17 Posts
I like them too. The old friction Suntour barcons are really smooth and have a great feel. I like the 7speed Suntour or Shimano units but they are pricey. Even the barcons are $35 these days. I was just thinking the other day that Sunrace ought to make a new less pricey option.
Tape wrapping has a few issues. You can start at the bottom out with the tape starting just after the shifter cable but pulled tight. Some use double sided tape to ensure a permanent stick. Others do the usual overlap and use the barend like a plug. That can be tricky as the fit is usually pretty tight. I have used Suntour shifters with Shimano cassettes and vise versa. They work but I try to use like brands.
I've sold a few bikes with old barcons and wished I hadn't. They are not getting any easier to find.
Cycle Tourist is offline
Old 09-04-19, 10:53 AM
  #9
bikemig
Senior Member

bikemig's Avatar

Join Date: Apr 2012
Location: Middle Earth (aka IA)
Posts: 15,763

Bikes: A bunch of old bikes and a few new ones

Mentioned: 124 Post(s)
Tagged: 0 Thread(s)
Quoted: 3878 Post(s)
Liked 211 Times in 174 Posts
I just installed suntour barcons on an early 70s Fuji Finest that I rebuilt. The suntour racheting downtube shifters were some of my favorite downtube shifters and I almost used them for this build. I'm glad I did not. The suntour barcons rock.

bikemig is online now
Old 09-04-19, 10:55 AM
  #10
Cycle Tourist
Senior Member

Join Date: Jan 2017
Posts: 300
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 96 Post(s)
Likes: 0
Liked 19 Times in 17 Posts
Originally Posted by Slightspeed View Post
Being a downtube shifter hater, I love my bar cons, with preference to Suntour with the ratchet clicks. I find them more precise and just easier to use in friction mode than my Campy ones, that I have been riding since 1964. Over 50 + years of riding I've managed to avoid DT shifters, but I now have two in my collection, Simplex on a '78 Peugeot PR10, and old Campy DTs on a '61 Legnano that I just couldn't resist. I actually had a set of Suntour bar cons for the PR10, but before I could get them switched, a needy Raleigh Super Course showed up that got them. The cable routing makes for lively discussion, but as for me, rather than having them hanging out in the breeze, I like mine tucked up under the bar tape, exiting near the stem. I find that they shift great, and don't snag on everything that passes near them, and just look more tidy.

Suntours on a recent build '78 Raleigh. With aero brake levers and shifter cables, it gets crowded under the bar tape, but it works for me, and I like the clean look.


Campy bar ends on my '64 Legnano, 55 years of trouble free operation, just don't feel as nice as the Suntours.
Very interesting. I've always had my cables come straight out with the least amount of bend but I really like the look of your setup. Thanks for letting me know there are no issues with shifting. That's my new look from now on.
Cycle Tourist is offline
Old 09-04-19, 11:00 AM
  #11
52telecaster
ambulatory senior

52telecaster's Avatar

Join Date: Dec 2016
Location: Peoria Il
Posts: 2,761

Bikes: Bob Jackson World Tour, Falcon and 98 Bianchi Volpe

Mentioned: 40 Post(s)
Tagged: 0 Thread(s)
Quoted: 849 Post(s)
Likes: 0
Liked 64 Times in 39 Posts
Suntours are great, modern frictions are made by diacomp and work well.
52telecaster is offline
Old 09-04-19, 11:05 AM
  #12
Slightspeed
Senior Member

Slightspeed's Avatar

Join Date: Apr 2017
Location: Los Angeles, CA
Posts: 1,732

Bikes: 1961 Legnano Gran Premio, 1964 Legnano Roma Olympiade, 1973 Raleigh Super Course, 1978 Raleigh Super Course, 1978 Peugeot PR10, 2002 Specialized Allez, 2007 Specialized Roubaix, 2013 Culprit Croz Blade

Mentioned: 54 Post(s)
Tagged: 0 Thread(s)
Quoted: 542 Post(s)
Likes: 0
Liked 182 Times in 121 Posts
Originally Posted by Cycle Tourist View Post
Very interesting. I've always had my cables come straight out with the least amount of bend but I really like the look of your setup. Thanks for letting me know there are no issues with shifting. That's my new look from now on.
My '64 Legnano (had since new) had the cables routed under the tape and exiting near the stem, as did my brother's Raleigh Grand Prix. I didn't know there was any other way, till I saw a few on Bikeforums, which I'm fairly new to. The only issue, is that the cables can rub on the head tube paint, especially the stainless steel cable housing. You can use clear plastic stickers to protect the paint, or slip a piece of rubber or plastic tubing over the housing.


My brother's Raleigh, original cable routing.

Bits of rubber hose over cable housing to protect paint.

Last edited by Slightspeed; 09-04-19 at 11:12 AM.
Slightspeed is offline
Old 09-04-19, 02:36 PM
  #13
ClemY
Senior Member

Join Date: Jun 2008
Location: Maryland
Posts: 565

Bikes: Hollands Touring Bike, Schwinn mountain bike, folding bike, tandem and triple

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Shift levers, like so much else in life, are a matter of personal preference. I tried the Sun Tour and didn't care for them. I used Campy friction barcons for many years until I finally went with indexed Shimano barcons. I don't think I would ever go back.
ClemY is offline
Old 09-04-19, 02:58 PM
  #14
randyjawa
Senior Member

randyjawa's Avatar

Join Date: Apr 2007
Location: Thunder Bay, Ontario, Canada - burrrrr!
Posts: 9,315

Bikes: 1958 Rabeneick 120D, 1968 Legnano Gran Premio, Rocky Mountain Cardiac

Mentioned: 158 Post(s)
Tagged: 0 Thread(s)
Quoted: 649 Post(s)
Likes: 0
Liked 100 Times in 80 Posts
I have run Campy, Simplex and Suntour and Suntour Accushift. The Accushift shifters, that I use on the Bianchi that I keep in Jamaica, are absolutely perfect for me. Notot once have I missed a shift. The shifters are so good, in my opinion, that I bought a second set to install on my Rocky Mountain drop bar mountain bike...


And, for what it is worth, a set of Campy barcons will be fitted to my old Rabineick 120d once the paint work is finished...
__________________
"98% of the bikes I buy are projects". Learn how to find, restore and maintain vintage road bicycles at... MY "TEN SPEEDS"
randyjawa is offline
Old 09-04-19, 03:19 PM
  #15
JohnDThompson
Old fart

JohnDThompson's Avatar

Join Date: Nov 2004
Location: Appleton WI
Posts: 20,620

Bikes: Several, mostly not name brands.

Mentioned: 115 Post(s)
Tagged: 0 Thread(s)
Quoted: 1804 Post(s)
Liked 133 Times in 98 Posts
Simplex made a retrofriction bar-end shifter, which, like the downtube retrofriction shifter, tends to be pricey. But if you can justify the cost, the buttery-smooth feel is to die for.

JohnDThompson is offline
Old 09-04-19, 03:51 PM
  #16
Miele Man
Senior Member

Join Date: Jun 2014
Location: Ontario, Canada
Posts: 2,165

Bikes: Miele Latina, Miele Suprema, Miele Uno SL, Miele MTB, Bianchi Model Unknown, Fiori Venezia, VeloSport Adamas AX

Mentioned: 7 Post(s)
Tagged: 0 Thread(s)
Quoted: 341 Post(s)
Liked 49 Times in 38 Posts
I have both 8-speed (Ultegra iirc) and 9-Speed Dura Ace bar end shifters. Either can be used in friction mode as well as index mode. I think that Suntour bar end shifters are less expensive when they can be found.

Cheers
Miele Man is offline
Old 09-04-19, 05:04 PM
  #17
garryg
Senior Member
Thread Starter

Join Date: Sep 2018
Location: Campbell River BC
Posts: 117
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 34 Post(s)
Liked 13 Times in 8 Posts
Just the kind of info i was looking for,thank you all.
garryg is offline
Old 09-04-19, 05:50 PM
  #18
due ruote
Senior Member

due ruote's Avatar

Join Date: Dec 2006
Posts: 6,854
Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 556 Post(s)
Liked 49 Times in 34 Posts
Itís a good idea to use a drop of Loctite on the Suntour locknuts.

Shimano made 6/7 speed indexed barcons, but they arenít as ubiquitous as the 8+ speed varieties. The default was 7 speeds, and to make them 6-speed, a small crescent shaped plastic do-dad had to be snapped into the cable slot to modify the cable pull.
due ruote is offline
Old 09-04-19, 08:55 PM
  #19
67tony
Senior Member

67tony's Avatar

Join Date: Feb 2012
Location: Williamsburg, VA Sebastian, FL
Posts: 980

Bikes: 1987 Centurion Ironman Master, 1992 Koga Miyata Exerciser, 1992 Schwinn Crosscut

Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 90 Post(s)
Likes: 0
Liked 2 Times in 2 Posts
I know these are merely stem shifters, but the Suntour Power Shifters have very crisp ratcheting, while the Shimano Finger Tips have both a return spring and ratcheting.

67tony is offline
Old 09-04-19, 09:31 PM
  #20
ddeand
Senior Member

ddeand's Avatar

Join Date: Jul 2004
Location: Twin Cities
Posts: 731
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 134 Post(s)
Liked 21 Times in 10 Posts
A quick question for those of you who have touted the cables fully along the underside if the handlebars (under the bar tape): did you need to use extra-long cables for the rear derailleur, or were you able to use standard kit length cables? Thanks!
__________________
Some days, it's not even worth gnawing through the restraints.
ddeand is offline
Old 09-04-19, 09:44 PM
  #21
seypat
Senior Member

Join Date: Oct 2010
Posts: 4,291
Mentioned: 56 Post(s)
Tagged: 0 Thread(s)
Quoted: 1094 Post(s)
Likes: 0
Liked 164 Times in 123 Posts
Originally Posted by ddeand View Post
A quick question for those of you who have touted the cables fully along the underside if the handlebars (under the bar tape): did you need to use extra-long cables for the rear derailleur, or were you able to use standard kit length cables? Thanks!
Yes. Use a tandem shifter cable.
seypat is offline
Old 09-04-19, 09:52 PM
  #22
seypat
Senior Member

Join Date: Oct 2010
Posts: 4,291
Mentioned: 56 Post(s)
Tagged: 0 Thread(s)
Quoted: 1094 Post(s)
Likes: 0
Liked 164 Times in 123 Posts
I am one that prefers the Shimano Fingertip L600s over the ratcheting Suntours. If you need the feedback, get the Suntours. No feedback with the L600s. You think it, you move it, that's it. Repeat as necessary. They are that smooth.
seypat is offline
Old 09-04-19, 10:30 PM
  #23
ddeand
Senior Member

ddeand's Avatar

Join Date: Jul 2004
Location: Twin Cities
Posts: 731
Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 134 Post(s)
Liked 21 Times in 10 Posts
Originally Posted by seypat View Post
Yes. Use a tandem shifter cable.
Thanks, I appreciate the response.
__________________
Some days, it's not even worth gnawing through the restraints.
ddeand is offline
Related Topics
Thread
Thread Starter
Forum
Replies
Last Post
RAMJ84
Bicycle Mechanics
11
04-07-15 10:48 AM
Rifleman
Touring
31
05-19-14 02:49 PM
TurbineBlade
Classic & Vintage
47
08-20-13 10:33 PM
JBHoren
Classic & Vintage
2
05-09-13 05:32 PM
c_bake
Classic & Vintage
51
09-21-11 02:13 PM

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off


Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

Copyright © 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
