Can the frame be indentified by measurements only...?

Hi all,

I previously posted this under 'Mercian or Carlton; this time I have added more detail in terms of measurements.

I've had the frame pictured below for a number of years, given to me by my brother-in-law. There is no marking or serial number upon the frame or forks, and when it was given to me the only clue to its original colour was a hint of metallic red on the steerer. I did contact Mercian as their lugs look very similar to the ones on my frame. Mercian thought it was a Campionissimo from between 69-74. I did ask them whether they would ever let a frame leave the factory with no serial numbers, but the thread went dead. I'm not convinced it is a Campionissimo. I live in Bedfordshire and there was a frame builder in the next county (TEW Reynolds) who also used similar lugs in the 60's-70's so I thought it could be one of theirs...but they just don't quite match. In a last attempt to get some form of identification I have taken extensive measurements in the hope that someone will take a guess at the quality of the steel, which may then point me in a direction....


Top tube ext. diameter 25.93mm
Down Tube " 28.77mm
Seat tube " 28.90mm
Head tube " 31.97mm; wall thickness 2.77mm; inside diameter 29.99mm
Chainstay " 22.32mm (at BB); 13.00mm at drop out
Seat stay " 13mm (seat post end); 10.55mm at drop out
Bottom Bracket " 39.94mm; wall thickness 3.22mm; inside diameter 33.12mm
Seat tube lug thickness: 3.40mm; inside diameter 26.27mm


Frame weight: 2.41kg (5.32lbs)
Fork weight: 920g (32.5oz)

Any help in anyway to get a handle on this frame would be really welcome. It rides beautifully and as a winter frame with Suntour and ofmega group set it's a joy; just wish I could badge it up as well.

Many thanks







Gerald

Last edited by maiello; 04-19-19 at 08:45 AM. Reason: Clarification
maiello is offline
Old 04-19-19, 09:41 AM
  #2
T-Mar
Senior Member

Join Date: Nov 2004
Posts: 17,829
Mentioned: 431 Post(s)
Tagged: 1 Thread(s)
Quoted: 2474 Post(s)
Likes: 0
Liked 58 Times in 54 Posts
The best way way to "indentify" a frame, is to strike it with a heavy object.
T-Mar is offline
Old 04-19-19, 10:44 AM
  #3
USAZorro
Señor Member

USAZorro's Avatar

Join Date: Oct 2004
Location: Florence, KY
Posts: 16,214

Bikes: Mostly English - predominantly Raleighs

Mentioned: 48 Post(s)
Tagged: 0 Thread(s)
Quoted: 695 Post(s)
Liked 8 Times in 8 Posts
No serial on the steerer either?

What diameter seat post?
__________________
In search of what to search for.
USAZorro is offline
Old 04-19-19, 11:02 AM
  #4
unterhausen
Randomhead

Join Date: Aug 2008
Location: Happy Valley, Pennsylvania
Posts: 18,240
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Liked 33 Times in 30 Posts
looks like he measured 26.27mm seatpost.
unterhausen is offline
Old 04-19-19, 11:18 AM
  #5
USAZorro
Señor Member

USAZorro's Avatar

Join Date: Oct 2004
Location: Florence, KY
Posts: 16,214

Bikes: Mostly English - predominantly Raleighs

Mentioned: 48 Post(s)
Tagged: 0 Thread(s)
Quoted: 695 Post(s)
Liked 8 Times in 8 Posts
Originally Posted by unterhausen View Post
looks like he measured 26.27mm seatpost.
I see it now. That's some heavy gauge tubing.
__________________
In search of what to search for.
USAZorro is offline
Old 04-19-19, 01:44 PM
  #6
malcala622
Senior Member

malcala622's Avatar

Join Date: Oct 2014
Location: Pico Rivera, CA
Posts: 1,968

Bikes: Bianchi Trofeo/Limited/Giro.Tommasini Prestige. Bottecchia Cromor. Gios Torino. Torelli Strada?

Mentioned: 56 Post(s)
Tagged: 0 Thread(s)
Quoted: 518 Post(s)
Likes: 0
Liked 16 Times in 14 Posts
Originally Posted by T-Mar View Post
The best way way to "indentify" a frame, is to strike it with a heavy object.
I see what u did there
malcala622 is online now
Old 04-19-19, 02:05 PM
  #7
rando_couche
Senior Member

Join Date: Jul 2013
Posts: 1,058
Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 133 Post(s)
Likes: 0
Liked 12 Times in 10 Posts
Originally Posted by USAZorro View Post
I see it now. That's some heavy gauge tubing.
Wouldn't that be in the right range for high-quality plain gauge tubing? (531pg, durifort, etc)

SP
Nwpt, OR
rando_couche is offline
Old 04-19-19, 02:58 PM
  #8
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by USAZorro View Post
No serial on the steerer either?

What diameter seat post?
Unfortunately no numbers anywhere, complete blank canvas... Maybe a local frame builder got hold of the tubes...
maiello is offline
Old 04-19-19, 03:01 PM
  #9
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by rando_couche View Post
Wouldn't that be in the right range for high-quality plain gauge tubing? (531pg, durifort, etc)

SP
Nwpt, OR
If it were a Mercian then posibly could be 531. I did check Reynolds dimensions, and they weren't quite a match: sometimes outside diameter was lower than Reynolds, some time higher only by a decimal point, so possibly given human involvement could be 531. Not heard of Durifort....
maiello is offline
Old 04-19-19, 03:03 PM
  #10
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by malcala622 View Post
I see what u did there
Just got it 😊
maiello is offline
Old 04-19-19, 03:23 PM
  #11
CliffordK
Senior Member

CliffordK's Avatar

Join Date: Nov 2014
Location: Eugene, Oregon, USA
Posts: 22,486
Mentioned: 166 Post(s)
Tagged: 0 Thread(s)
Quoted: 8518 Post(s)
Liked 73 Times in 65 Posts
There are some measurements such as headbadge holes that are apparently very representative of brands. But, lacking those features, one goes by overall features of the bike.

Also, identifying threads, post sizes, & etc, could help identify the tubing and country of origin.

Identifying the dropouts may also help narrow down both the age of the frame, as well as potentially builders or country of origin.
CliffordK is offline
Old 04-19-19, 03:59 PM
  #12
VcruzX
Junior Member

Join Date: Apr 2019
Posts: 16
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Likes: 0
Liked 1 Time in 1 Post
Nice frame.
VcruzX is offline
Old 04-19-19, 06:37 PM
  #13
repechage
Senior Member

Join Date: Jun 2006
Posts: 13,341
Mentioned: 77 Post(s)
Tagged: 0 Thread(s)
Quoted: 936 Post(s)
Likes: 0
Liked 13 Times in 11 Posts
rear dropouts appear closer to stamped than forged, but does have a derailleur tab, machined cable stops for shift cables adjacent to the bottom bracket.
LONG top eyes, "production" effort to the lugs... My conjecture straight gauge tubing... But, double check the seat lug ears are not distorted inward.

shine a bright light down the head tube looking for headbadge fastener holes. My feeling is this is older than younger.
repechage is offline
Old 04-20-19, 02:21 AM
  #14
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by CliffordK View Post
There are some measurements such as headbadge holes that are apparently very representative of brands. But, lacking those features, one goes by overall features of the bike.

Also, identifying threads, post sizes, & etc, could help identify the tubing and country of origin.

Identifying the dropouts may also help narrow down both the age of the frame, as well as potentially builders or country of origin.
That's the shame of it: no identifying marks, holes, numbers or names... Just quite distinctive lugs. The dropouts look to be pressed steel, no branding. That's why I wonder whether a local frame builder got hold of the tubes. Don't know if this helps in anyway, but I've attached a pic of the inside of the bottom bracket.

Last edited by maiello; 04-20-19 at 02:57 AM.
maiello is offline
Old 04-20-19, 02:22 AM
  #15
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by VcruzX View Post
Nice frame.
Thank you. A bit heavy, but smooth and comfortable on wintry rds.
maiello is offline
Old 04-20-19, 02:26 AM
  #16
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts

Originally Posted by repechage View Post
rear dropouts appear closer to stamped than forged, but does have a derailleur tab, machined cable stops for shift cables adjacent to the bottom bracket.
LONG top eyes, "production" effort to the lugs... My conjecture straight gauge tubing... But, double check the seat lug ears are not distorted inward.

shine a bright light down the head tube looking for headbadge fastener holes. My feeling is this is older than younger.
I think so. Dropouts definitely plain pressed steel, no branding at all. Just the lugs make it a bit different. Completely subjective, with no real evidence, it feels 1960ish.

Last edited by maiello; 04-20-19 at 02:54 AM.
maiello is offline
Old 04-20-19, 05:29 AM
  #17
non-fixie
Shifting is fun!

non-fixie's Avatar

Join Date: Aug 2009
Location: South Holland, NL
Posts: 7,727

Bikes: Yes, please.

Mentioned: 190 Post(s)
Tagged: 0 Thread(s)
Quoted: 1058 Post(s)
Liked 41 Times in 33 Posts
Nice frame! Any idea where it might have come from?

Unmarked frames from the seventies and eighties are quite common in my area. Most came from Belgium, where a number of shops and factories produced frames for others to brand and sell. They were made at various quality levels, from very mundane Flandrias to pro spec Martens one-offs.
__________________
Reasons to be cheerful!
non-fixie is offline
Old 04-20-19, 05:39 AM
  #18
bertinjim
Senior Member

bertinjim's Avatar

Join Date: Mar 2012
Location: Niagara Region, Canada
Posts: 966

Bikes: 1960s Bertin C37, 1970s Bertin C 37

Mentioned: 22 Post(s)
Tagged: 0 Thread(s)
Quoted: 155 Post(s)
Likes: 0
Liked 3 Times in 3 Posts
maiello -




It looks like one of the better mid-range Carltons from the very late 60s or 70s. The tells are the Crespera lugs, the Vagner DP+ style crown, the post style cable stops and the use of the Zeus stamped dropouts which are all characteristic of that period of Carlton construction. The tubing is likely to have been TI TruWell 205 plain gauge hi-tensile which seems consistent with the weights you provided. Try the Veteran Cycle Club's on line catalogues here: Veteran-Cycle Club Online Library
bertinjim is offline
Old 04-20-19, 06:25 AM
  #19
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by non-fixie View Post
Nice frame! Any idea where it might have come from?

Unmarked frames from the seventies and eighties are quite common in my area. Most came from Belgium, where a number of shops and factories produced frames for others to brand and sell. They were made at various quality levels, from very mundane Flandrias to pro spec Martens one-offs.
Sorry, no idea. My brother in law often picks up old frames from skips and tips, could have come from anywhere. I live in England, and it's nice to imagine that some point it might have ridden across Belgium cobbles.
maiello is offline
Old 04-20-19, 06:29 AM
  #20
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by bertinjim View Post
maiello -




It looks like one of the better mid-range Carltons from the very late 60s or 70s. The tells are the Crespera lugs, the Vagner DP+ style crown, the post style cable stops and the use of the Zeus stamped dropouts which are all characteristic of that period of Carlton construction. The tubing is likely to have been TI TruWell 205 plain gauge hi-tensile which seems consistent with the weights you provided. Try the Veteran Cycle Club's on line catalogues here: Veteran-Cycle Club Online Library
Thank you for that. I was edging towards Carlton Clubman from the sixties. I'll check out the lead... Checking on other forums I came across this: 1969 carlton longfellow. Identical lugs, carlton brochure states it is made out of heavier 531 tubing for the taller rider. Sadly no other pictures on the thread I took this from.

https://images.app.goo.gl/Q52yJenbPwADqDrA8

Last edited by maiello; 04-20-19 at 08:49 AM.
maiello is offline
Old 04-20-19, 09:00 AM
  #21
CliffordK
Senior Member

CliffordK's Avatar

Join Date: Nov 2014
Location: Eugene, Oregon, USA
Posts: 22,486
Mentioned: 166 Post(s)
Tagged: 0 Thread(s)
Quoted: 8518 Post(s)
Liked 73 Times in 65 Posts
Originally Posted by maiello View Post
That's the shame of it: no identifying marks, holes, numbers or names... Just quite distinctive lugs. The dropouts look to be pressed steel, no branding. That's why I wonder whether a local frame builder got hold of the tubes. Don't know if this helps in anyway, but I've attached a pic of the inside of the bottom bracket.
I always think of small backyard frame building when something obscure shows up. However, few small builders are working with pressed steel dropouts, at least today.

One might note that my Colnago Super has all the proper clover cutouts, but no serial numbers or other markings.

I read some speculation once that Colnago may have deliberately not serialized the early frames to fudge taxes.
CliffordK is offline
Old 04-20-19, 11:24 AM
  #22
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by CliffordK View Post
I always think of small backyard frame building when something obscure shows up. However, few small builders are working with pressed steel dropouts, at least today.

One might note that my Colnago Super has all the proper clover cutouts, but no serial numbers or other markings.

I read some speculation once that Colnago may have deliberately not serialized the early frames to fudge taxes.
Nice bike, one day....

I think I'm the closest I will ever get: 60's - 70's Carlton; either a long fellow with heavy 531 as it says in the catalogue, or maybe a Clubman with straightforward plain gauge. If not more specific decals, I'd be happy to badge it as a Carlton, particularly as I am a fan of the Raleigh brand as well.
maiello is offline
Old 05-02-19, 11:58 AM
  #23
maiello
Senior Member
Thread Starter

Join Date: Jun 2011
Location: Bedfordshire, England
Posts: 97

Bikes: Peugeot (753r frame-1989), Raleigh (Reynolds 653-1991).

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Likes: 0
Liked 0 Times in 0 Posts
Well... Committed to the Carlton badge. All set to be kitted out for winter.
maiello is offline
Old 05-02-19, 12:08 PM
  #24
rustystrings61
Senior Member

Join Date: May 2013
Location: Greenwood SC USA
Posts: 764

Bikes: 2002 Mercian Vincitore, 1982 Mercian Colorado, 1976 Puch Royal X, 1973 Raleigh Competition, 1971 Gitane Tour de France and others

Mentioned: 29 Post(s)
Tagged: 0 Thread(s)
Quoted: 263 Post(s)
Liked 31 Times in 19 Posts
The lugs look like Bocama products to me, like some variant of the model 80 - perhaps a variant dropped by the time they printed this catalog, which shows similar lugs -
rustystrings61 is online now
Old 05-02-19, 01:01 PM
  #25
non-fixie
Shifting is fun!

non-fixie's Avatar

Join Date: Aug 2009
Location: South Holland, NL
Posts: 7,727

Bikes: Yes, please.

Mentioned: 190 Post(s)
Tagged: 0 Thread(s)
Quoted: 1058 Post(s)
Liked 41 Times in 33 Posts
Excellent! Looking forward to the rest of the build.
__________________
Reasons to be cheerful!
non-fixie is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

Copyright © 2018 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
