Running a smaller rim up front?

Notices
General Cycling Discussion Have a cycling related question or comment that doesn't fit in one of the other specialty forums? Drop on in and post in here! When possible, please select the forum above that most fits your post!

Running a smaller rim up front?

Old 01-09-21, 09:48 PM
  #1
Moisture
Drip, Drip.
Thread Starter

Moisture's Avatar

Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,489

Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 989 Post(s)
Liked 170 Times in 143 Posts
Running a smaller rim up front?

Do you think there could be any benefit in doing so with the correct size fork?

My idea is that this could aid in front end agility while keeping the rear end more stable. However, I think that anything more than 1cm in overall rim diameter might not work quite so optimally. Or is it best to simply refer to making tweaks to the geometry of the frame itself?,
Moisture is offline
Old 01-09-21, 10:08 PM
  #2
base2
Doesn't brain good.

base2's Avatar

Join Date: Jun 2015
Location: Pacific Northwest
Posts: 1,933

Bikes: 5 good ones, and the occasional project.

Mentioned: 18 Post(s)
Tagged: 0 Thread(s)
Quoted: 1000 Post(s)
Liked 652 Times in 387 Posts
We used to do this sort of mix & match as kids screwin' around the neighborhood. I even had a tiny scooter wheel on my BMX bike for awhile.

As for usefulness? I don't think there is really much benefit to doing so randomly. But practicality aside, & assuming disc brakes, there are cases where it could theoretically make sense. One example would be installing a suspension fork on a 29'er/700c rigid. 54x559 is really close to 700x23c. In theory you could swap in a suspension fork & 26x2.1 tire & not terribly disturb headtube angle/rake too terribly...not that it would make sense for most bikes though--The rear wheel would need frame clearance. I wouldn't take such a bike over more than a generically rough road with potholes, though.

Usually people just keep their rigid as a rigid & go with 27.5/650b for the additional tire volume.

Last edited by base2; 01-09-21 at 10:17 PM.
base2 is offline
Old 01-10-21, 04:32 AM
  #3
canklecat
Me duelen las nalgas

canklecat's Avatar

Join Date: Aug 2015
Location: Texas
Posts: 13,221

Bikes: Centurion Ironman, Trek 5900, Univega Via Carisma, Globe Carmel

Mentioned: 195 Post(s)
Tagged: 0 Thread(s)
Quoted: 4386 Post(s)
Liked 2,418 Times in 1,568 Posts
Check out the 1980s time trial bikes (and a few track bikes) with smaller diameter front wheels and drastically raked geometry, an attempt to get more aero -- before aero bars made that style obsolete while retaining more traditional frame geometry. Handling on those goofy bikes of the 1980s was probably sketchy and demanding of rider skill and attention.

Terry, Centurion and maybe one other maker offered smaller frames for women with a smaller diameter front wheel but a more traditional looking frame geometry. But those are for folks around 5'2" or shorter. Handling was said to feel like any traditional diamond frame bike.

Many recumbent and low slung foot-forward bike designs use smaller diameter front wheels. I've tried one and could not get the hang of it. Due more to the recumbent design than the wheel.
canklecat is offline
Likes For canklecat:
Old 01-10-21, 07:13 AM
  #4
Moisture
Drip, Drip.
Thread Starter

Moisture's Avatar

Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,489

Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 989 Post(s)
Liked 170 Times in 143 Posts
Maybe it could work with a more subtle difference between the two wheels
Moisture is offline
Old 01-10-21, 08:16 AM
  #5
skidder
Bipsycorider

Join Date: Sep 2012
Location: Orange County, California
Posts: 1,423

Bikes: Why yes, I do have a few! Thank you for asking!

Mentioned: 11 Post(s)
Tagged: 0 Thread(s)
Quoted: 746 Post(s)
Liked 559 Times in 387 Posts
Seeing how particular front fork rake/wheel size is related, any changes in size would put the steering and frame geometry out of whack. I replaced a rigid fork on an early 90s MTB with a suspension-corrected fork (80mm larger) and it made the front end really floppy, definitely could not ride it 'no-hands' (the bike's frame was small so I was trying to get more height on the front end). Not sure how it would work if you wanted to change it only 1-2 cm. And if you're changing wheel size you 're going to have to account for that in your roadside repair kit (larger/smaller tube(s) for a flat).
skidder is offline
Old 01-10-21, 08:23 AM
  #6
dedhed
SE Wis

dedhed's Avatar

Join Date: Apr 2005
Location: Milwaukee, WI
Posts: 8,827

Bikes: '68 Raleigh Sprite, '02 Raleigh C500, '84 Raleigh Gran Prix, '91 Trek 400, 2013 Novara Randonee, 1990 Trek 970

Mentioned: 32 Post(s)
Tagged: 0 Thread(s)
Quoted: 2054 Post(s)
Liked 1,996 Times in 1,242 Posts
Common enough design in the past for small riders. Georgina Terry, Shogun among others.
These bikes were designed from the bottom up to run a smaller front wheel. Good luck having brakes reach.

https://www.bikeforums.net/classic-v...-knockoff.html

https://www.bikeforums.net/classic-v...-symmetry.html
dedhed is offline
Old 01-10-21, 08:51 AM
  #7
Kapusta
Cyclochondriac

Kapusta's Avatar

Join Date: Feb 2017
Posts: 5,340

Bikes: Soma Fog Cutter, Surly Wednesday, Turner 5-Spot, Canfielld Tilt

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 2343 Post(s)
Liked 1,974 Times in 1,098 Posts
You should definitely do this.

If you donít lead the way into this uncharted territory, who will?
Kapusta is offline
Old 01-10-21, 08:58 AM
  #8
BlazingPedals
Senior Member

BlazingPedals's Avatar

Join Date: Dec 2004
Location: Middle of da Mitten
Posts: 12,100

Bikes: Trek 7500, RANS V-Rex, Optima Baron, Velokraft NoCom, M-5 Carbon Highracer, Catrike Speed

Mentioned: 14 Post(s)
Tagged: 0 Thread(s)
Quoted: 1373 Post(s)
Liked 529 Times in 345 Posts
Going to a smaller front wheel will make the bike twitchier by increasing the head tube angle, if that's your goal. You can also accomplish it by getting a fork with more rake. Do you have a disc brake on the front, or are you planning on losing a front brake?
BlazingPedals is offline
Old 01-10-21, 09:02 AM
  #9
rosefarts
With a mighty wind

Join Date: May 2015
Posts: 1,979
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 775 Post(s)
Liked 504 Times in 295 Posts
It's not uncommon to run a larger size front wheel than the rear. On mountain bikes.

It's almost like riders prefer a stable front end over some twitchy thing that jumps all over with the slightest bump.

See also, the gradual increase in handlebar width and the once ubiquitous 26" wheel becoming essentially obsolete.
rosefarts is offline
Old 01-10-21, 09:57 AM
  #10
cxwrench
Senior Member

cxwrench's Avatar

Join Date: Jul 2013
Location: Nor-Cal
Posts: 2,863

Bikes: lots

Mentioned: 4 Post(s)
Tagged: 0 Thread(s)
Quoted: 1405 Post(s)
Liked 1,956 Times in 1,039 Posts
People actually think about lots of different things when they design bicycles. Many of them have to do w/ handling, and safety. Sure, you could design a frame w/ say a 700c rear and a 650c front but to put a smaller front wheel on a bike that was designed to have the same size wheels front and rear is just stupid. Seriously OP...think about these things for minute before making these posts. Do a little research.
cxwrench is offline
Likes For cxwrench:
Old 01-10-21, 09:59 AM
  #11
rydabent
Senior Member

rydabent's Avatar

Join Date: Apr 2010
Location: Lincoln Ne
Posts: 9,320

Bikes: RANS Stratus TerraTrike Tour II

Mentioned: 35 Post(s)
Tagged: 0 Thread(s)
Quoted: 2651 Post(s)
Liked 850 Times in 495 Posts
My RANS STRATUS runs a smaller wheel up front. (20") It makes for better aerodynamics.
rydabent is offline
Old 01-10-21, 10:30 AM
  #12
alcjphil
Senior Member

alcjphil's Avatar

Join Date: Jun 2002
Location: Montreal, Quebec
Posts: 4,851
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
Quoted: 1321 Post(s)
Liked 848 Times in 525 Posts
I have a friend who bought a bike with a smaller front wheel years ago. He is very short, just 5 feet tall. The bike in question was custom built with a 650c front wheel and a 700c rear wheel, both with tubular tires. A year later he had ditched that bike for a Giant with 2 700c wheels. He told me that having 2 different tire sizes was a real nuisance having to carry 2 different tires on rides in case of flats. As well, 650c tubulars are hard to find
alcjphil is offline
Old 01-10-21, 11:34 AM
  #13
Happy Feet
Senior Member

Happy Feet's Avatar

Join Date: Sep 2015
Location: Left Coast, Canada
Posts: 5,126
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 2235 Post(s)
Liked 1,303 Times in 702 Posts
Originally Posted by rydabent View Post
My RANS STRATUS runs a smaller wheel up front. (20") It makes for better aerodynamics.
Uh... on your recumbent bike.
Way to not confuse the issue.

OP, as noted some manufacturers have used a smaller wheel to improve aerodynamics (now an obsolete idea) or prevent toe strikes. I can't think of any who have done so to improve handling.
Happy Feet is offline
Old 01-10-21, 12:32 PM
  #14
downtube42
Senior Member

downtube42's Avatar

Join Date: Oct 2008
Location: Portland, OR
Posts: 3,160

Bikes: Soma Fog Cutter, Volae Team, Focus Mares AL, Nimbus MUni, Trek Roscoe 6.

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 604 Post(s)
Liked 1,351 Times in 686 Posts
Originally Posted by alcjphil View Post
I have a friend who bought a bike with a smaller front wheel years ago. He is very short, just 5 feet tall. The bike in question was custom built with a 650c front wheel and a 700c rear wheel, both with tubular tires. A year later he had ditched that bike for a Giant with 2 700c wheels. He told me that having 2 different tire sizes was a real nuisance having to carry 2 different tires on rides in case of flats. As well, 650c tubulars are hard to find
There is the impracticality of having to deal with two sizes of tubes and tires. Not to offend with bringing up recumbents, but my reason for going from a 26/20 to 26/26 format was to avoid this particular issue.

Changing fork and wheel on a bike designed for symmetric wheel sizes is going to alter handling, and probably not in a good way. Head tube angle is changed. You could use fork rake to try minimizing that effect. You've also changed seat tube angle, which affects CG fore/aft. To compensate for that you may need to adjust saddle fore/aft and stem length. Those changes have their effects.

Having said all that, if the OP wants to fool around with this, go for it. It's just time and money. Nothing ventured nothing gained. Too bad most bike co-ops are closed, because that would be a good source of cheap parts and people who like to screw around with bikes.
downtube42 is offline
Old 01-10-21, 02:45 PM
  #15
KenCT
Senior Member

Join Date: Feb 2019
Location: Connecticut
Posts: 179

Bikes: Cannondale Synapse Carbon 105 (2021) Cannondale Cujo 2 (2018) Cannondale Quick Carbon 1 (2017) Giant Sedona (2006) Cannondale R1000 (2001)

Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 56 Post(s)
Liked 201 Times in 94 Posts
I purchased the Raleigh for my girlfriend, now my wife, around 1988. 27" rear, 24" front. I believe it was called a proportional bike. My wife is a little over 5' tall and it fit her but she only rode it a few times. I held on to it until last year and it ended up as part of a swap/purchase for an older Cannondale for my trainer.

KenCT is offline
Old 01-10-21, 02:55 PM
  #16
Moisture
Drip, Drip.
Thread Starter

Moisture's Avatar

Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,489

Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 989 Post(s)
Liked 170 Times in 143 Posts
Originally Posted by BlazingPedals View Post
Going to a smaller front wheel will make the bike twitchier by increasing the head tube angle, if that's your goal. You can also accomplish it by getting a fork with more rake. Do you have a disc brake on the front, or are you planning on losing a front brake?
My fork already has a good amount of rske to make up for the slacker head tube .

My seat tube and head tube ate fairly slack, so the smaller front rim would probably be good for the handling of the bike. I'll take off the front brake sometime and try a 5 minute ride with it setup rjis way for fun.
Moisture is offline
Old 01-10-21, 03:05 PM
  #17
Kapusta
Cyclochondriac

Kapusta's Avatar

Join Date: Feb 2017
Posts: 5,340

Bikes: Soma Fog Cutter, Surly Wednesday, Turner 5-Spot, Canfielld Tilt

Mentioned: 26 Post(s)
Tagged: 0 Thread(s)
Quoted: 2343 Post(s)
Liked 1,974 Times in 1,098 Posts
Kapusta is offline
Old 01-10-21, 03:15 PM
  #18
Moisture
Drip, Drip.
Thread Starter

Moisture's Avatar

Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,489

Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 989 Post(s)
Liked 170 Times in 143 Posts
Originally Posted by BlazingPedals View Post
Going to a smaller front wheel will make the bike twitchier by increasing the head tube angle, if that's your goal. You can also accomplish it by getting a fork with more rake. Do you have a disc brake on the front, or are you planning on losing a front brake?
Originally Posted by downtube42 View Post
There is the impracticality of having to deal with two sizes of tubes and tires. Not to offend with bringing up recumbents, but my reason for going from a 26/20 to 26/26 format was to avoid this particular issue.

Changing fork and wheel on a bike designed for symmetric wheel sizes is going to alter handling, and probably not in a good way. Head tube angle is changed. You could use fork rake to try minimizing that effect. You've also changed seat tube angle, which affects CG fore/aft. To compensate for that you may need to adjust saddle fore/aft and stem length. Those changes have their effects.

Having said all that, if the OP wants to fool around with this, go for it. It's just time and money. Nothing ventured nothing gained. Too bad most bike co-ops are closed, because that would be a good source of cheap parts and people who like to screw around with bikes.
I already have a 26" front wheel laying around which I can play around with temporarily to test out, as I obviously don't want to ditch my front brake.

My local,bikehub is still open and has been a great place to obtain bike parts and fix stuff up .
Moisture is offline
Old 01-10-21, 03:48 PM
  #19
rydabent
Senior Member

rydabent's Avatar

Join Date: Apr 2010
Location: Lincoln Ne
Posts: 9,320

Bikes: RANS Stratus TerraTrike Tour II

Mentioned: 35 Post(s)
Tagged: 0 Thread(s)
Quoted: 2651 Post(s)
Liked 850 Times in 495 Posts
Originally Posted by downtube42 View Post
There is the impracticality of having to deal with two sizes of tubes and tires. Not to offend with bringing up recumbents, but my reason for going from a 26/20 to 26/26 format was to avoid this particular issue.

Changing fork and wheel on a bike designed for symmetric wheel sizes is going to alter handling, and probably not in a good way. Head tube angle is changed. You could use fork rake to try minimizing that effect. You've also changed seat tube angle, which affects CG fore/aft. To compensate for that you may need to adjust saddle fore/aft and stem length. Those changes have their effects.

Having said all that, if the OP wants to fool around with this, go for it. It's just time and money. Nothing ventured nothing gained. Too bad most bike co-ops are closed, because that would be a good source of cheap parts and people who like to screw around with bikes.
Not really a big deal. Both my bike and trike have 20/26 wheels. I carry several stick in boots, and have yet to use one, and have never walked home. I carry patchs, and two boxes of appropriate size tubes in my trunk pack.

BTW if your bike has 20 inch wheels in front and 26 inch wheels in back, you are faster since you are alway riding down hill!!!
rydabent is offline
Old 01-10-21, 03:50 PM
  #20
rydabent
Senior Member

rydabent's Avatar

Join Date: Apr 2010
Location: Lincoln Ne
Posts: 9,320

Bikes: RANS Stratus TerraTrike Tour II

Mentioned: 35 Post(s)
Tagged: 0 Thread(s)
Quoted: 2651 Post(s)
Liked 850 Times in 495 Posts
Originally Posted by Kapusta View Post
Absolutely!!!!!!!!
rydabent is offline
Old 01-10-21, 05:05 PM
  #21
downtube42
Senior Member

downtube42's Avatar

Join Date: Oct 2008
Location: Portland, OR
Posts: 3,160

Bikes: Soma Fog Cutter, Volae Team, Focus Mares AL, Nimbus MUni, Trek Roscoe 6.

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 604 Post(s)
Liked 1,351 Times in 686 Posts
Originally Posted by rydabent View Post
Not really a big deal. Both my bike and trike have 20/26 wheels. I carry several stick in boots, and have yet to use one, and have never walked home. I carry patchs, and two boxes of appropriate size tubes in my trunk pack.

BTW if your bike has 20 inch wheels in front and 26 inch wheels in back, you are faster since you are alway riding down hill!!!
I rode a 26/20 V-Rex for over 10 years. Included 2 Paris-Brest-Paris finishes, numerous 24 hour races, numerous Super Randonneur series. Point being, many miles far from home, alone, and totally self reliant. Since both my wheel sizes were outside the norm, I couldn't rely on other people or the limited support available to help me out with spares. Even bike shops are iffy, when you need a 26x1.25 or 20x1.25 tube or worse tire. So I carried lots of tubes, and 2 tires, for a ton of miles. In all those years, I used all my 26" tubes once, and suffered one unrecoverable tire failure. Never DNFd.

Now on the longest events I carry 4 tubes and 1 tire. It's better. On my upright, I'm giving tubeless a go, but that's another story.

My experience isn't typical, I realize; most people don't ride stupidly long distances in remote places.
downtube42 is offline
Old 01-10-21, 05:10 PM
  #22
rosefarts
With a mighty wind

Join Date: May 2015
Posts: 1,979
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Quoted: 775 Post(s)
Liked 504 Times in 295 Posts
Originally Posted by rydabent View Post
Not really a big deal. Both my bike and trike have 20/26 wheels. I carry several stick in boots, and have yet to use one, and have never walked home. I carry patchs, and two boxes of appropriate size tubes in my trunk pack.

BTW if your bike has 20 inch wheels in front and 26 inch wheels in back, you are faster since you are alway riding down hill!!!
Easy to carry extra stuff on a lawn chair with pedals.
rosefarts is offline
Likes For rosefarts:
Old 01-11-21, 09:31 AM
  #23
Happy Feet
Senior Member

Happy Feet's Avatar

Join Date: Sep 2015
Location: Left Coast, Canada
Posts: 5,126
Mentioned: 24 Post(s)
Tagged: 0 Thread(s)
Quoted: 2235 Post(s)
Liked 1,303 Times in 702 Posts
Originally Posted by Moisture View Post
I already have a 26" front wheel laying around which I can play around with temporarily to test out, as I obviously don't want to ditch my front brake.

My local,bikehub is still open and has been a great place to obtain bike parts and fix stuff up .
post pics.
Happy Feet is offline
Old 01-24-21, 09:57 PM
  #24
Moisture
Drip, Drip.
Thread Starter

Moisture's Avatar

Join Date: Oct 2020
Location: Southern Ontario
Posts: 1,489

Bikes: Trek Verve E bike, Felt Doctrine 4 XC, Opus Horizon Apex 1

Mentioned: 8 Post(s)
Tagged: 0 Thread(s)
Quoted: 989 Post(s)
Liked 170 Times in 143 Posts
Originally Posted by Happy Feet View Post
post pics.
I finally got around to doing it. Here's a pic:

Moisture is offline
Old 01-24-21, 10:27 PM
  #25
veganbikes
Clark W. Griswold

Join Date: Mar 2014
Location: ,location, location
Posts: 9,720

Bikes: Foundry Chilkoot Ti W/Ultegra Di2, Salsa Timberjack Ti, Cinelli Mash Work RandoCross Fun Time Machine, 1x9 XT Parts Hybrid, Co-Motion Cascadia, Specialized Langster, Phil Wood Apple VeloXS Frame (w/DA 7400), R+M Supercharger2 Rohloff, Habanero Ti 26

Mentioned: 42 Post(s)
Tagged: 0 Thread(s)
Quoted: 2796 Post(s)
Liked 1,955 Times in 1,294 Posts
Originally Posted by Moisture View Post
I finally got around to doing it. Here's a pic:

Wrong spot send it to GCN for the Hacks and Bodges though don't worry about the first part, it's a bodge.
veganbikes is offline

Thread Tools
Search this Thread

Contact Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service - Do Not Sell My Personal Information -

Copyright © 2021 MH Sub I, LLC dba Internet Brands. All rights reserved. Use of this site indicates your consent to the Terms of Use.
